The Omcan 48412 Wok Range
The Omcan CE-CN-W1L1-NG is a single-chamber natural gas wok range rated at 125,000 BTU, built for the high-heat stir-frying, deep-frying, and stock-boiling demands of Chinese, Thai, and other Asian cuisine kitchens. Each chamber concentrates intense heat from jet burners directly under the wok, delivering the rapid temperature response that wok cooking requires. The unit comes with a stainless steel backsplash, faucet, and pipe rack as standard equipment.
High-Output Jet Burners with Water-Cooled Top
The 16-inch ring uses a 28-tip jet burner rated at 125,000 BTU. The multi-tip design spreads flame evenly around the base of the wok rather than concentrating it in a single point, which means your wok heats uniformly and you get consistent searing across the entire cooking surface. The water-cooled top keeps the work surface at a manageable temperature for the cook, even with burners running at full output for hours during service. Each burner has an adjustable gas valve with pilot ignition for quick, reliable lighting.
Stainless Steel Backsplash with Integrated Faucet
The built-in backsplash protects the wall behind the range from grease splatter and steam damage. The stainless steel faucet with water inlet and drain (both 1/2-inch NPT female) provides running water right at the cooking station for rinsing woks between dishes, adding water to stocks, and quick cleanup during service. The pipe rack above the backsplash gives you a place to hang ladles, strainers, and other wok tools within arm's reach.
Gas connects through a 3/4-inch NPT rear connection, and a pressure regulator is supplied with the unit. Operating pressure is 5.0 inches water column with a recommended supply pressure of 7 to 9 inches water column. The range requires 6 inches of clearance from combustible construction on all sides. At 121 pounds with overall dimensions of 27.8" x 44" x 62", this unit fits into the wok station of a professional kitchen line.
About Omcan
For over 74 years, Omcan has been a trusted name in the foodservice industry across Canada and the United States. Built on consistency, credibility, and long-standing customer relationships, Omcan offers a dependable range of products to support a wide range of operations. With a global network and localized service, the brand delivers complete solutions—from smallwares to advanced equipment. In 2024, Omcan introduced the Trento brand, representing a curated lineup of European foodservice equipment available exclusively in North America. Whether supporting independent operators or institutional kitchens, Omcan is focused on practical performance and reliable service.
Features & Benefits
-
High-output single-chamber wok range for Chinese, Thai, and Asian kitchens demanding maximum heat
-
125,000 BTU from a 28-tip jet burner on a 16" ring delivers the intense flame needed for authentic wok hei
-
Larger 16" ring accommodates bigger woks for high-volume stir-frying, deep-frying, and stock boiling
-
Water-cooled top manages surface temperature while directing all heat into the wok
-
Adjustable gas valve with pilot ignition gives cooks responsive flame control
-
Stainless steel faucet, backsplash, and pipe rack included for a complete wok station
-
Runs on natural gas with 3/4" NPT rear connection
-
1/2" NPT water inlet and drain for the integrated cooling system
-
Operating pressure: 5.0" W.C. (recommended supply: 7-9" W.C.); regulator supplied
-
Requires 6" clearance from combustible construction
Free Shipping 48 Contiguous states & DC only.
In Stock: Ships in 1-2 Business Days
High-output single-chamber wok range for Chinese, Thai, and Asian kitchens demanding maximum heat
125,000 BTU from a 28-tip jet burner on a 16" ring delivers the intense flame needed for authentic wok hei
Larger 16" ring accommodates bigger woks for high-volume stir-frying, deep-frying, and stock boiling
Water-cooled top manages surface temperature while directing all heat into the wok
Adjustable gas valve with pilot ignition gives cooks responsive flame control
The Omcan 48412 Wok Range
The Omcan CE-CN-W1L1-NG is a single-chamber natural gas wok range rated at 125,000 BTU, built for the high-heat stir-frying, deep-frying, and stock-boiling demands of Chinese, Thai, and other Asian cuisine kitchens. Each chamber concentrates intense heat from jet burners directly under the wok, delivering the rapid temperature response that wok cooking requires. The unit comes with a stainless steel backsplash, faucet, and pipe rack as standard equipment.
High-Output Jet Burners with Water-Cooled Top
The 16-inch ring uses a 28-tip jet burner rated at 125,000 BTU. The multi-tip design spreads flame evenly around the base of the wok rather than concentrating it in a single point, which means your wok heats uniformly and you get consistent searing across the entire cooking surface. The water-cooled top keeps the work surface at a manageable temperature for the cook, even with burners running at full output for hours during service. Each burner has an adjustable gas valve with pilot ignition for quick, reliable lighting.
Stainless Steel Backsplash with Integrated Faucet
The built-in backsplash protects the wall behind the range from grease splatter and steam damage. The stainless steel faucet with water inlet and drain (both 1/2-inch NPT female) provides running water right at the cooking station for rinsing woks between dishes, adding water to stocks, and quick cleanup during service. The pipe rack above the backsplash gives you a place to hang ladles, strainers, and other wok tools within arm's reach.
Gas connects through a 3/4-inch NPT rear connection, and a pressure regulator is supplied with the unit. Operating pressure is 5.0 inches water column with a recommended supply pressure of 7 to 9 inches water column. The range requires 6 inches of clearance from combustible construction on all sides. At 121 pounds with overall dimensions of 27.8" x 44" x 62", this unit fits into the wok station of a professional kitchen line.
About Omcan
For over 74 years, Omcan has been a trusted name in the foodservice industry across Canada and the United States. Built on consistency, credibility, and long-standing customer relationships, Omcan offers a dependable range of products to support a wide range of operations. With a global network and localized service, the brand delivers complete solutions—from smallwares to advanced equipment. In 2024, Omcan introduced the Trento brand, representing a curated lineup of European foodservice equipment available exclusively in North America. Whether supporting independent operators or institutional kitchens, Omcan is focused on practical performance and reliable service.
Features & Benefits
-
High-output single-chamber wok range for Chinese, Thai, and Asian kitchens demanding maximum heat
-
125,000 BTU from a 28-tip jet burner on a 16" ring delivers the intense flame needed for authentic wok hei
-
Larger 16" ring accommodates bigger woks for high-volume stir-frying, deep-frying, and stock boiling
-
Water-cooled top manages surface temperature while directing all heat into the wok
-
Adjustable gas valve with pilot ignition gives cooks responsive flame control
-
Stainless steel faucet, backsplash, and pipe rack included for a complete wok station
-
Runs on natural gas with 3/4" NPT rear connection
-
1/2" NPT water inlet and drain for the integrated cooling system
-
Operating pressure: 5.0" W.C. (recommended supply: 7-9" W.C.); regulator supplied
-
Requires 6" clearance from combustible construction
Resources & Downloads
See all from Omcan
Specifications
| Fuel Type | Natural Gas |
| Chamber Configuration | 1 chamber (16" ring) |
| Total BTU Output | 125,000 |
| Number of Burners | 1 |
| Burner Type | Jet burners (13" ring: 18-tip / 16" ring: 28-tip) |
| Ignition | Pilot |
| Top Cooling | Water-cooled |
| Gas Valve | Adjustable |
| Gas Connection | 3/4" NPT rear |
| Operating Pressure | 5.0" W.C. |
| Recommended Supply Pressure | 7 to 9" W.C. |
| Water Inlet | 1/2" NPT female |
| Water Drain | 1/2" NPT female |
| Backsplash | Stainless steel (included) |
| Faucet | Stainless steel (included) |
| Pipe Rack | Stainless steel (included) |
| Regulator | Supplied |
| Clearance from Combustibles | 6" |
| Net Weight | 121 lbs |
| Overall Dimensions (WxDxH) | 27.8" x 44" x 62" |
Manufacturer's Warranty
-
1 Year
Labor
-
1 Year
Parts
