The Sealer Sales SS-180L Gravity Curved Conveyor
The Sealer Sales SS-180L is a 180 degree gravity curved conveyor (curve section only, no straight section) for left to right product flow. The 180 degree curve returns the package back along the production line so a single operator can both feed and offload from one position. Use this with a discharge straight section already provided by another conveyor or the sealer line itself.
Left to Right Flow
This SKU is the Left to Right variant: product enters on one side of the curve and exits on the opposite side. Pick the L-direction variant that matches the discharge direction of the upstream sealer or tunnel.
Curve-Only Configuration
This SKU is the 180 degree curve only, no straight runout section. Use it in line layouts that already provide a runout straight from another conveyor or from the sealer line itself.
3/4" Aluminum Rollers on 1-1/4" Centers
Aluminum rollers spaced on 1.25 inch centers carry packages smoothly across the curve without snag points. Aluminum is lighter than steel rollers so the conveyor moves easily for reconfiguration.
Stainless Steel Concentric Curve Wall
The outer edge of the curve is a stainless steel concentric wall that keeps packages on the conveyor through the turn. This is what prevents packages from sliding off the outer radius under their own momentum.
Adjustable Height Legs, 28 to 44 inches
Painted height-adjustable legs let the operator match the conveyor height to the discharge point of the upstream sealer or tunnel. Range covers most bench-height production layouts.
Package End Stop
A package end stop is included at the conveyor exit to prevent runoff when downstream pickup is delayed. The stop is positioned so packages queue cleanly without falling off.
Features & Benefits
-
15 inch wide conveyor belt
-
Left to Right flow direction
-
180 degree curve returns product flow back along the line
-
3/4" aluminum rollers on 1-1/4" centers
-
Stainless steel concentric outer curve wall keeps packages on the conveyor
-
Painted height-adjustable legs, 28 to 44 inch range
-
Includes an end stop at the conveyor exit to prevent runoff
-
Gravity-fed, no motor or power required
-
Designed to extend or redirect product flow off the discharge of bench-top L-Bar sealers, shrink tunnels, or similar packaging equipment
Free Shipping 48 Contiguous states & DC only.
In Stock: Ships in 1-2 Business Days
15 inch wide conveyor belt
Left to Right flow direction
180 degree curve returns product flow back along the line
3/4" aluminum rollers on 1-1/4" centers
Stainless steel concentric outer curve wall keeps packages on the conveyor
The Sealer Sales SS-180L Gravity Curved Conveyor
The Sealer Sales SS-180L is a 180 degree gravity curved conveyor (curve section only, no straight section) for left to right product flow. The 180 degree curve returns the package back along the production line so a single operator can both feed and offload from one position. Use this with a discharge straight section already provided by another conveyor or the sealer line itself.
Left to Right Flow
This SKU is the Left to Right variant: product enters on one side of the curve and exits on the opposite side. Pick the L-direction variant that matches the discharge direction of the upstream sealer or tunnel.
Curve-Only Configuration
This SKU is the 180 degree curve only, no straight runout section. Use it in line layouts that already provide a runout straight from another conveyor or from the sealer line itself.
3/4" Aluminum Rollers on 1-1/4" Centers
Aluminum rollers spaced on 1.25 inch centers carry packages smoothly across the curve without snag points. Aluminum is lighter than steel rollers so the conveyor moves easily for reconfiguration.
Stainless Steel Concentric Curve Wall
The outer edge of the curve is a stainless steel concentric wall that keeps packages on the conveyor through the turn. This is what prevents packages from sliding off the outer radius under their own momentum.
Adjustable Height Legs, 28 to 44 inches
Painted height-adjustable legs let the operator match the conveyor height to the discharge point of the upstream sealer or tunnel. Range covers most bench-height production layouts.
Package End Stop
A package end stop is included at the conveyor exit to prevent runoff when downstream pickup is delayed. The stop is positioned so packages queue cleanly without falling off.
Features & Benefits
-
15 inch wide conveyor belt
-
Left to Right flow direction
-
180 degree curve returns product flow back along the line
-
3/4" aluminum rollers on 1-1/4" centers
-
Stainless steel concentric outer curve wall keeps packages on the conveyor
-
Painted height-adjustable legs, 28 to 44 inch range
-
Includes an end stop at the conveyor exit to prevent runoff
-
Gravity-fed, no motor or power required
-
Designed to extend or redirect product flow off the discharge of bench-top L-Bar sealers, shrink tunnels, or similar packaging equipment
See all from Sealer Sales
Specifications
| Specification | Detail |
|---|---|
| Straight Section | 24" |
| Height | 28" - 44" |
| Gross Weight (lbs) | 43 |
| Shipping Dimensions | 48" x 27" x 23" |
Manufacturer's Warranty
-
6 Month
Labor
-
6 Month
Parts
