UNOX XACC-0513-MPLM 21 In. Electric Countertop Combi Oven (Single-Phase), (5) GN 1/1 Capacity, MIND.Maps Plus Touch Controls, AISI 316L Stainless Steel Chamber

The UNOX XACC-0513-EPRM is the combi oven for the small-footprint kitchen that still has to cook like a big one. It is the 5-pan compact in the ChefTop MIND.Maps Plus line, sized for quick service lines, c-store hot programs, catering kitchens, and ghost kitchens that have 21 inches of counter to spare but still need steaming, roasting, baking, regeneration, and sous-vide on the same unit. The 9.5" touch panel runs the MIND.Maps interface, where a line cook draws a cooking process on the screen instead of programming it step by step, and the 1000+ stored recipes let unskilled staff drop a pan in, pick a name, and walk away to the same result the corporate chef built during recipe development.

(5) GN 1/1 Pan Capacity in a 21-Inch Footprint

Five full-size GN 1/1 hotel pans (or 12" x 20" hotel pans) stage in a cabinet that is 21-1/16" wide, 34-5/16" deep, and 25-9/16" tall, with 2-5/8" between rack positions. The compact draws 7.7 kW from 240V single-phase service (32.5 amps) or 5.8 kW from 208V single-phase (28.5 amps), both off a 40A breaker through a NEMA 6-50P plug, so the install drops onto the same panel feeding the rest of the line with no service upgrade.

AISI 316L Stainless Steel Cooking Chamber

The cooking chamber is AISI 316L stainless, the marine-grade alloy that resists pitting from chlorides in steam-heavy operation. Standard 304 chambers in cheaper combis can corrode at the welds after a few years of daily steaming, because the salt and acid environment eats the weak points in the metal. 316L holds up because the molybdenum in the alloy resists that failure mode. Internal edges are rounded, so a closer wipes the chamber down without a brush working into corners.

MIND.Maps Touch Controls and the Intelligent Cooking Suite

The 9.5" capacitive touch panel runs MIND.Maps drawable cooking processes, 1000+ stored programs, MULTI.TIME (up to 10 simultaneous cooking processes on the same load), and MISE.EN.PLACE staggered pan insertion so plated items finish together. ADAPTIVE.Cooking watches the load and adjusts parameters in real time, so a half load and a full load finish to the same standard without operator intervention. CLIMALUX gives total humidity control in the chamber for items that need it. SMART.Preheating sets preheat values automatically. AUTO.Soft manages the heat rise so delicate items do not shock, and SENSE.Klean reads how dirty the chamber is and recommends the right wash cycle.

Steam Performance and Core-Probe Cooking

STEAM.Maxi produces saturated steam, DRY.Maxi rapidly pulls humidity out for crisp surfaces, AIR.Maxi runs the 4-speed fan in auto-reverse and pulse so the airflow does not strip moisture off soft loads, and PRESSURE.Steam raises steam saturation and temperature for tougher cuts. The temperature range is 86°F to 500°F across all modes, with up to 9 steps per program. The standard MULTI.Point core probe reads from 4 points in the protein, so a thick end and a thin end finish at the same internal temperature instead of the thin end being overcooked. Delta T cooking holds the chamber at a fixed offset above the core temperature for low-and-slow proteins. An optional 2-point SOUS-VIDE core probe handles vacuum-bag cooking.

ROTOR.Klean Automatic Wash and Integrated DET&Rinse

ROTOR.Klean runs an automatic wash cycle that cleans the chamber and runs a special cycle behind the fan guard, the spot where grease and limescale collect and most operators skip during nightly cleanup. The DET&Rinse detergent container is integrated into the cabinet, so there is no drum on the floor and no hose to a wall dispenser. SENSE.Klean picks the wash based on actual chamber soil level instead of running the heaviest cycle every night.

Integrated Wi-Fi and USB for HACCP Data

Built-in Wi-Fi pushes HACCP cooking data to UNOX's Data Driven Cooking app, so the compliance log writes itself and you can pull it for a health inspection without standing at the oven with a clipboard. The same connection lets a corporate chef push new recipes to every store in the chain overnight. USB transfer is built in for sites where Wi-Fi is not reliable.

Triple-Glass Door with LED Chamber Lighting

Triple-glazed glass keeps the outer pane cool enough to brush against without burning a forearm, and the chamber LEDs are embedded in the door itself, so light hits the load from the front. The drip collection system is integrated in the door and keeps catching condensate even when the door is open during loading.

Install-Ready with Water Line, Ventless Hood Option, Stand, and Filter

The water line to reach a 3/4" MPT connection within three feet of the oven ships in the box. UNOX requires water treatment when total hardness exceeds 8 dH on the steam circuit, and the optional PURE / PURE.XL resin filter handles that on a single inlet. Other accessories include the ventless steam-condensing hood for buildouts without engineered exhaust, Cooking Essentials specialty trays, DET&Rinse ECO and ULTRAPLUS detergents, the Ethernet connection kit for hardwired data, and the optional 2-point SOUS-VIDE core probe.

Right-Sized For, And Not For

This is the right oven for QSR lines, c-store hot programs, catering kitchens, hotel pantry stations, ghost kitchens, and any compact concept that needs true combi capability without the floor space or the electrical capacity for a full-size combi. If you are running a full-service kitchen that needs 10 or 20 GN 1/1 pans at a time, the larger ChefTop MIND.Maps Plus units in the UNOX lineup are the right call.
