Cavavin V-024WDZFGB 15 In. 24-Bottle Dual Zone Wine Cellar, Black Lacquered Aluminum Front with LOW-E Glass, Invisible Handle, Built-In or Freestanding

SKUV-024WDZFGB BrandCAVAVIN

The CAVAVIN V-024WDZFGB Wine Cooler

The Cavavin V-024WDZFGB holds 24 bottles of 750 ml in a 15-inch wide undercounter cabinet with a black lacquered aluminum front panel and an invisible handle. The door reads as a single flat black surface, so the cabinet disappears into dark cabinetry or a bar front. Two independent temperature zones let you keep whites and reds at their separate serving temperatures in the same cabinet.

Two Independent Temperature Zones for Reds and Whites

The upper zone holds 41-54°F (5-12°C), the range where you keep whites, roses, and lighter reds you plan to serve soon. The lower zone runs 50-68°F (10-20°C) for the fuller reds and ports you want at cellar or serving temperature. Each zone is managed from the LCD touchscreen on the door, so you can dial in both side by side without opening the cabinet. An internal fan keeps air moving so the set temperature is the same at the top of the zone as at the bottom.

Seamless Stainless Steel Frame with LOW-E Double Glazing

The black lacquered aluminum front panel is flush with the frame and has no visible handle: a recessed pull along the top edge opens the door. The black flush-fit hinges match the panel for a single uninterrupted black surface when the door is closed. The LOW-E double-pane glass rejects radiant heat and UV light, so sunlight and room heat do not shift the temperature inside or fade the labels on your bottles. The seamless frame has no visible fasteners, and a charcoal filter in the airflow path keeps the interior free of odors that would otherwise work into corks over time.

Beech Wood Shelves and Tri-Color LED Lighting

Five beech wood shelves sit on full-extension sliding rails, so every bottle pulls forward all the way for easy reach without shuffling the one in front. The interior LED strip has three color settings (warm white, cool white, blue) and can run continuously or switch on only when the door opens. The lock keeps the contents secure, and a door-open alarm tells you if someone leaves it ajar. A small-caster foot at the back lets you position the cabinet by yourself during install.

Built-In or Freestanding, Variable-Speed Compressor

The cabinet fits flush into a 15-inch undercounter cut-out thanks to front-vented airflow, or stands alone against a wall. The variable-speed compressor runs quiet (42 dB) and ramps up only when the cabinet needs more cooling, which is easier on the electric bill than a single-speed compressor that cycles full-on and full-off. Refrigerant is R-600a, a hydrocarbon that has a much lower global warming impact than the synthetic refrigerants in most older wine cellars.

Features & Benefits

  1. Designed for a 15-inch undercounter cut-out or a freestanding position in a kitchen, bar, dining room, or home office
  2. Capacity: 24 bottles of 750 ml
  3. Two independent temperature zones: upper 41-54°F (5-12°C), lower 50-68°F (10-20°C)
  4. Black lacquered aluminum front panel with double-pane LOW-E glass
  5. Black flush-fit hinges
  6. Invisible recessed handle along the top edge of the door
  7. 5 beech wood shelves on full-extension sliding rails
  8. Reversible door: No
  9. Variable-speed compressor that ramps cooling capacity to match cabinet demand
  10. Exterior dimensions: H 34.25" x W 14.96" x D 23.62"
  11. Net weight: 90 lbs
  12. LCD touchscreen display on the door shows each zone temperature and locks the setpoint to prevent accidental changes
  13. Seamless stainless steel door frame with no visible fasteners
  14. LOW-E double-pane anti-UV glass rejects radiant heat and ultraviolet light to protect labels and contents
  15. Tri-color interior LED lighting (warm white, cool white, blue) with continuous or door-activated modes
  16. Charcoal filter in the airflow path keeps outside odors out of the cabinet
  17. Stainless steel kickplate and silent fan (42 dB) for quiet, discreet operation
  18. Lock and door-open alarm for secured access
  19. R-600a hydrocarbon refrigerant with a low global warming impact
  20. Copper evaporator for efficient heat exchange
  21. Small casters at the back of the cabinet for easier install
  22. CSA certified for use in North America
  23. Built-in front-vented installation or freestanding against a wall

Free Shipping ? 48 Contiguous states & DC only.

In Stock: Ships in 1-2 Business Days

$1,313.12
  • Designed for a 15-inch undercounter cut-out or a freestanding position in a kitchen, bar, dining room, or home office
  • Capacity: 24 bottles of 750 ml
  • Two independent temperature zones: upper 41-54°F (5-12°C), lower 50-68°F (10-20°C)
  • Black lacquered aluminum front panel with double-pane LOW-E glass
  • Black flush-fit hinges
  • See full feature list

    The CAVAVIN V-024WDZFGB Wine Cooler

    The Cavavin V-024WDZFGB holds 24 bottles of 750 ml in a 15-inch wide undercounter cabinet with a black lacquered aluminum front panel and an invisible handle. The door reads as a single flat black surface, so the cabinet disappears into dark cabinetry or a bar front. Two independent temperature zones let you keep whites and reds at their separate serving temperatures in the same cabinet.

    Two Independent Temperature Zones for Reds and Whites

    The upper zone holds 41-54°F (5-12°C), the range where you keep whites, roses, and lighter reds you plan to serve soon. The lower zone runs 50-68°F (10-20°C) for the fuller reds and ports you want at cellar or serving temperature. Each zone is managed from the LCD touchscreen on the door, so you can dial in both side by side without opening the cabinet. An internal fan keeps air moving so the set temperature is the same at the top of the zone as at the bottom.

    Seamless Stainless Steel Frame with LOW-E Double Glazing

    The black lacquered aluminum front panel is flush with the frame and has no visible handle: a recessed pull along the top edge opens the door. The black flush-fit hinges match the panel for a single uninterrupted black surface when the door is closed. The LOW-E double-pane glass rejects radiant heat and UV light, so sunlight and room heat do not shift the temperature inside or fade the labels on your bottles. The seamless frame has no visible fasteners, and a charcoal filter in the airflow path keeps the interior free of odors that would otherwise work into corks over time.

    Beech Wood Shelves and Tri-Color LED Lighting

    Five beech wood shelves sit on full-extension sliding rails, so every bottle pulls forward all the way for easy reach without shuffling the one in front. The interior LED strip has three color settings (warm white, cool white, blue) and can run continuously or switch on only when the door opens. The lock keeps the contents secure, and a door-open alarm tells you if someone leaves it ajar. A small-caster foot at the back lets you position the cabinet by yourself during install.

    Built-In or Freestanding, Variable-Speed Compressor

    The cabinet fits flush into a 15-inch undercounter cut-out thanks to front-vented airflow, or stands alone against a wall. The variable-speed compressor runs quiet (42 dB) and ramps up only when the cabinet needs more cooling, which is easier on the electric bill than a single-speed compressor that cycles full-on and full-off. Refrigerant is R-600a, a hydrocarbon that has a much lower global warming impact than the synthetic refrigerants in most older wine cellars.

    Features & Benefits

    1. Designed for a 15-inch undercounter cut-out or a freestanding position in a kitchen, bar, dining room, or home office
    2. Capacity: 24 bottles of 750 ml
    3. Two independent temperature zones: upper 41-54°F (5-12°C), lower 50-68°F (10-20°C)
    4. Black lacquered aluminum front panel with double-pane LOW-E glass
    5. Black flush-fit hinges
    6. Invisible recessed handle along the top edge of the door
    7. 5 beech wood shelves on full-extension sliding rails
    8. Reversible door: No
    9. Variable-speed compressor that ramps cooling capacity to match cabinet demand
    10. Exterior dimensions: H 34.25" x W 14.96" x D 23.62"
    11. Net weight: 90 lbs
    12. LCD touchscreen display on the door shows each zone temperature and locks the setpoint to prevent accidental changes
    13. Seamless stainless steel door frame with no visible fasteners
    14. LOW-E double-pane anti-UV glass rejects radiant heat and ultraviolet light to protect labels and contents
    15. Tri-color interior LED lighting (warm white, cool white, blue) with continuous or door-activated modes
    16. Charcoal filter in the airflow path keeps outside odors out of the cabinet
    17. Stainless steel kickplate and silent fan (42 dB) for quiet, discreet operation
    18. Lock and door-open alarm for secured access
    19. R-600a hydrocarbon refrigerant with a low global warming impact
    20. Copper evaporator for efficient heat exchange
    21. Small casters at the back of the cabinet for easier install
    22. CSA certified for use in North America
    23. Built-in front-vented installation or freestanding against a wall

    Specifications

    Bottle Capacity24 bottles (750 ml)
    Number of Temperature Zones2 (independent)
    Upper Zone Temperature Range41-54°F (5-12°C)
    Lower Zone Temperature Range50-68°F (10-20°C)
    Exterior Dimensions (H x W x D)34.25" x 14.96" x 23.62" (870 x 380 x 600 mm)
    Packing Dimensions (H x W x D)36.22" x 17.13" x 26.77" (920 x 435 x 680 mm)
    Net Weight90 lbs (41 kg)
    DoorSeamless stainless steel frame with double-pane LOW-E glass
    Front FinishBlack lacquered aluminum front panel with double-pane LOW-E glass
    HingesBlack flush-fit hinges
    HandleInvisible recessed handle
    Shelves5 beech wood shelves on full-extension sliding rails
    ControlLCD touchscreen display
    Interior LightingLED, 3 color options (warm white, cool white, blue), continuous or door-activated
    Air PurificationCharcoal filter
    Airflow SystemStainless steel kickplate with silent fan
    LockYes
    Door Opening AlarmYes
    Reversible DoorNo
    EvaporatorCopper
    CompressorVariable-speed, quiet and energy-efficient
    RefrigerantR-600a
    Noise Level42 dB
    MobilitySmall casters at the back
    InstallationBuilt-in (front-vented) or freestanding

    Manufacturer's Warranty

    • 1 Year

      Labor

    • 1 Year

      Parts
