Alexander Industries E-400 20 In. 11-Pan End Loading Bun Pan Rack, 5 in. Slide Spacing, Mobile, Aluminum

SKUE-400 BrandAlexander Industries

The Alexander Industries E-400 Bun pan rack

The Alexander Industries E-400 is an end loading aluminum bun pan rack that holds 11 full-size 18 x 26 in. bun pans on 5 in. centers. It is the standard open rack for bakeries, pizzerias, school kitchens and commissaries that need to stage sheet pans between the prep table, the oven and the cooling area. The wide 5 in. slide spacing gives you room for tall product, covered pans or 18 x 26 in. sheet pans loaded with bread loaves and layer cakes. The rack rolls on four swivel casters and arrives knocked down for assembly, with factory assembly available as an option.

6061-T6 Aluminum Extrusion Frame

Uprights and cross members are 1 in. square 6061-T6 aluminum extrusion, and each tray runner is a 1-7/16 x 1-7/8 in. extrusion of the same alloy. Aluminum will not rust in a walk-in cooler or under a daily hose-down, and the extruded runner has enough section to carry a fully loaded pan without sagging. Corners are tied together with .100 in. thick 3003-H14 aluminum brackets and aircraft quality aluminum rivets, so the frame stays square after years of being pushed through doorways.

5 In. Ball Bearing Swivel Casters

Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires let one person move a full rack across tile or sealed concrete without leaving scuffs. Two locking casters can be added when the rack parks next to an oven or in a proof box.

Optional Accessories

Alexander offers donut bumpers to protect walls and door frames, a tray stopper to keep pans from sliding out the open back, a sanitary rack cover for holding uncovered product, and a pair of locking casters. All fit this frame without modification.

Features & Benefits

Holds 11 full-size 18 x 26 in. bun pans on 5 in. slide spacing for proofing, cooling and staging
End loading open frame so pans slide in from the front without lifting over a side rail
1 in. square uprights and cross members extruded from 6061-T6 aluminum
Tray runners extruded from 1-7/16 x 1-7/8 in. 6061-T6 aluminum
Connecting brackets stamped from .100 in. thick 3003-H14 high tensile aluminum
Assembled with high tensile aircraft quality aluminum rivets
Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires
Arrives knocked down for on-site assembly, factory assembly available as an option
Optional accessories: donut bumpers, tray stopper, sanitary rack cover, two locking casters

Free Shipping ? 48 Contiguous states & DC only.

In Stock: Ships in 1-2 Business Days

$395.36

Holds 11 full-size 18 x 26 in. bun pans on 5 in. slide spacing for proofing, cooling and staging

End loading open frame so pans slide in from the front without lifting over a side rail

1 in. square uprights and cross members extruded from 6061-T6 aluminum

Tray runners extruded from 1-7/16 x 1-7/8 in. 6061-T6 aluminum

Connecting brackets stamped from .100 in. thick 3003-H14 high tensile aluminum

See full feature list

The Alexander Industries E-400 Bun pan rack

The Alexander Industries E-400 is an end loading aluminum bun pan rack that holds 11 full-size 18 x 26 in. bun pans on 5 in. centers. It is the standard open rack for bakeries, pizzerias, school kitchens and commissaries that need to stage sheet pans between the prep table, the oven and the cooling area. The wide 5 in. slide spacing gives you room for tall product, covered pans or 18 x 26 in. sheet pans loaded with bread loaves and layer cakes. The rack rolls on four swivel casters and arrives knocked down for assembly, with factory assembly available as an option.

6061-T6 Aluminum Extrusion Frame

Uprights and cross members are 1 in. square 6061-T6 aluminum extrusion, and each tray runner is a 1-7/16 x 1-7/8 in. extrusion of the same alloy. Aluminum will not rust in a walk-in cooler or under a daily hose-down, and the extruded runner has enough section to carry a fully loaded pan without sagging. Corners are tied together with .100 in. thick 3003-H14 aluminum brackets and aircraft quality aluminum rivets, so the frame stays square after years of being pushed through doorways.

5 In. Ball Bearing Swivel Casters

Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires let one person move a full rack across tile or sealed concrete without leaving scuffs. Two locking casters can be added when the rack parks next to an oven or in a proof box.

Optional Accessories

Alexander offers donut bumpers to protect walls and door frames, a tray stopper to keep pans from sliding out the open back, a sanitary rack cover for holding uncovered product, and a pair of locking casters. All fit this frame without modification.

Features & Benefits

Holds 11 full-size 18 x 26 in. bun pans on 5 in. slide spacing for proofing, cooling and staging
End loading open frame so pans slide in from the front without lifting over a side rail
1 in. square uprights and cross members extruded from 6061-T6 aluminum
Tray runners extruded from 1-7/16 x 1-7/8 in. 6061-T6 aluminum
Connecting brackets stamped from .100 in. thick 3003-H14 high tensile aluminum
Assembled with high tensile aircraft quality aluminum rivets
Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires
Arrives knocked down for on-site assembly, factory assembly available as an option
Optional accessories: donut bumpers, tray stopper, sanitary rack cover, two locking casters

Resources & Downloads

Alexander Industries E-400 Specsheet

Specifications

Pan Size Accommodated	18 x 26 in. bun pans
Pan Capacity	11 pans
Slide Spacing	5 in.
Loading Style	End loading
Overall Width	20 in.
Overall Depth	26 in.
Overall Height	68 in.
Upright and Cross Member	1 in. square 6061-T6 aluminum extrusion
Tray Runner	1-7/16 x 1-7/8 in. 6061-T6 aluminum extrusion
Connecting Brackets	.100 in. 3003-H14 aluminum stamping
Fasteners	Aircraft quality aluminum rivets
Casters	5 in. swivel, ball bearing
Caster Tires	Non-marking hard rubber
Mobility	Mobile
Assembly	Knocked down, factory assembly optional
Shipping Weight	32 lb

Manufacturer's Warranty

5 Year

Casters
Lifetime Year

Parts

Certifications & Approvals

NSF Approved
