The Alexander Industries HDOV-702-NESTING Oval Tray Rack
The Alexander Industries HDOV-702-NESTING is a heavy duty all welded aluminum oval tray rack that holds 10 oval trays up to 24 in. on 6 in. centers and is rated for a 1200 lb load. It suits banquet operations, hotels, hospitals and commissaries that stage plated platters in volume and push loaded racks all day. It is built in nesting construction, so empty racks slide into each other and a row of them takes up a fraction of the floor space of racks parked side by side. The 26 in. wide frame rolls on four swivel casters and arrives fully welded and ready to use.
1-1/2 In. Square All Welded Aluminum Frame
Uprights and cross members are 1-1/2 in. square 6061-T6 aluminum extrusion in .093 in. wall, and each tray runner is a 1 x 4 in. extrusion of the same alloy and wall. Every joint is welded rather than riveted, which is what lets the rack carry 1200 lb and shrug off the knocks of a loading dock. Aluminum will not rust in a walk-in cooler or under a daily hose-down.
6 In. Slide Spacing for 10 Oval Trays
The 6 in. spacing leaves room for a covered or garnished platter on every level, and ten runners stack in a 71 in. tall frame that fits through a standard door. Alexander sizes the runners to the oval tray you specify at ordering, 24 in. for this model.
5 In. Ball Bearing Swivel Casters
Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires let one person move a full rack across tile or sealed concrete without leaving scuffs. Optional donut bumpers, a tray stopper, a sanitary rack cover and a pair of locking casters fit your frame without modification.
Features & Benefits
-
Holds 10 oval trays up to 24 in. on 6 in. slide spacing for staging plated platters before service
-
All welded frame carries a 1200 pound load rating
-
Nesting construction so empty racks slide into one another for compact storage
-
1-1/2 in. square uprights and cross members extruded from .093 in. wall 6061-T6 aluminum
-
Tray runners extruded from 1 x 4 in. 6061-T6 aluminum with a .093 in. wall
-
Welded at every joint with no rivets or brackets to loosen
-
Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires
-
Arrives fully welded and ready to use
-
Runners sized to the oval tray specified at ordering, 24 in. for this model
-
Optional accessories: donut bumpers, tray stopper, sanitary rack cover, two locking casters
Free Shipping 48 Contiguous states & DC only.
In Stock: Ships in 1-2 Business Days
Holds 10 oval trays up to 24 in. on 6 in. slide spacing for staging plated platters before service
All welded frame carries a 1200 pound load rating
Nesting construction so empty racks slide into one another for compact storage
1-1/2 in. square uprights and cross members extruded from .093 in. wall 6061-T6 aluminum
Tray runners extruded from 1 x 4 in. 6061-T6 aluminum with a .093 in. wall
The Alexander Industries HDOV-702-NESTING Oval Tray Rack
The Alexander Industries HDOV-702-NESTING is a heavy duty all welded aluminum oval tray rack that holds 10 oval trays up to 24 in. on 6 in. centers and is rated for a 1200 lb load. It suits banquet operations, hotels, hospitals and commissaries that stage plated platters in volume and push loaded racks all day. It is built in nesting construction, so empty racks slide into each other and a row of them takes up a fraction of the floor space of racks parked side by side. The 26 in. wide frame rolls on four swivel casters and arrives fully welded and ready to use.
1-1/2 In. Square All Welded Aluminum Frame
Uprights and cross members are 1-1/2 in. square 6061-T6 aluminum extrusion in .093 in. wall, and each tray runner is a 1 x 4 in. extrusion of the same alloy and wall. Every joint is welded rather than riveted, which is what lets the rack carry 1200 lb and shrug off the knocks of a loading dock. Aluminum will not rust in a walk-in cooler or under a daily hose-down.
6 In. Slide Spacing for 10 Oval Trays
The 6 in. spacing leaves room for a covered or garnished platter on every level, and ten runners stack in a 71 in. tall frame that fits through a standard door. Alexander sizes the runners to the oval tray you specify at ordering, 24 in. for this model.
5 In. Ball Bearing Swivel Casters
Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires let one person move a full rack across tile or sealed concrete without leaving scuffs. Optional donut bumpers, a tray stopper, a sanitary rack cover and a pair of locking casters fit your frame without modification.
Features & Benefits
-
Holds 10 oval trays up to 24 in. on 6 in. slide spacing for staging plated platters before service
-
All welded frame carries a 1200 pound load rating
-
Nesting construction so empty racks slide into one another for compact storage
-
1-1/2 in. square uprights and cross members extruded from .093 in. wall 6061-T6 aluminum
-
Tray runners extruded from 1 x 4 in. 6061-T6 aluminum with a .093 in. wall
-
Welded at every joint with no rivets or brackets to loosen
-
Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires
-
Arrives fully welded and ready to use
-
Runners sized to the oval tray specified at ordering, 24 in. for this model
-
Optional accessories: donut bumpers, tray stopper, sanitary rack cover, two locking casters
Resources & Downloads
Specifications
| Tray Size Accommodated | 24 in. oval trays |
| Tray Capacity | 10 trays |
| Slide Spacing | 6 in. |
| Load Capacity | 1200 lb |
| Overall Width | 26 in. |
| Overall Depth | 26 in. |
| Overall Height | 71 in. |
| Upright and Cross Member | 1-1/2 in. square .093 in. wall 6061-T6 aluminum extrusion |
| Tray Runner | 1 x 4 in. 6061-T6 aluminum extrusion, .093 in. wall |
| Construction | All welded, nesting |
| Casters | 5 in. swivel, ball bearing |
| Caster Tires | Non-marking hard rubber |
| Mobility | Mobile |
| Assembly | Fully assembled |
| Shipping Weight | 51 lb |
Manufacturer's Warranty
-
5 Year
Casters
-
Lifetime Year
Parts
Certifications & Approvals
-
NSF Approved
