The Alexander Industries T-422 Bun pan rack
The Alexander Industries T-422 is a work table height end loading aluminum bun pan rack that holds 12 full-size 18 x 26 in. bun pans on 2 in. centers. At 35 in. tall it slides under a work table or parks at the end of the line as a low staging shelf for pizzerias, bakeries and commissaries that want a dozen pans close at hand. The 2 in. slide spacing packs more flat product such as cookies, pizza dough balls and portioned proteins into the same short frame. The rack rolls on four swivel casters and arrives knocked down for assembly, with factory assembly available as an option.
2 In. Slide Spacing for 12 Pans
Twelve pans on 2 in. centers doubles the count of the 4 in. version for flat product that does not need headroom. Pans load from the 20 in. end, so the rack can sit with one side against a wall or table leg and still be worked from the front. The flat top frame doubles as a landing spot at counter height.
6061-T6 Aluminum Extrusion Frame
Uprights and cross members are 1 in. square 6061-T6 aluminum extrusion, and each tray runner is a 1-7/16 x 1-7/8 in. extrusion of the same alloy. Aluminum will not rust in a walk-in cooler or under a daily hose-down. The connecting brackets for the bun pan shelves are included and stamped from .100 in. thick 3003-H14 aluminum, and the frame is assembled with aircraft quality aluminum rivets so it stays square in daily use.
5 In. Ball Bearing Swivel Casters
Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires let you roll a loaded rack across tile or sealed concrete without scuffing the floor. Two locking casters can be added when the rack parks under a table, along with donut bumpers, a tray stopper, a sanitary rack cover or a plastic cutting board for the top.
Features & Benefits
-
Holds 12 full-size 18 x 26 in. bun pans on 2 in. slide spacing for staging, proofing and cooling
-
Work table height 35 in. frame that rolls under a prep table or stands beside it as a staging shelf
-
End loading open frame so pans slide in from the 20 in. end without lifting over a side rail
-
1 in. square uprights and cross members extruded from 6061-T6 aluminum
-
Tray runners extruded from 1-7/16 x 1-7/8 in. 6061-T6 aluminum
-
Connecting brackets for the bun pan shelves included, stamped from .100 in. thick 3003-H14 high tensile aluminum
-
Assembled with high tensile aircraft quality aluminum rivets
-
Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires
-
Arrives knocked down for on-site assembly, factory assembly available as an option
-
Optional accessories: donut bumpers, tray stopper, sanitary rack cover, two locking casters, plastic cutting board
Free Shipping 48 Contiguous states & DC only.
In Stock: Ships in 1-2 Business Days
Holds 12 full-size 18 x 26 in. bun pans on 2 in. slide spacing for staging, proofing and cooling
Work table height 35 in. frame that rolls under a prep table or stands beside it as a staging shelf
End loading open frame so pans slide in from the 20 in. end without lifting over a side rail
1 in. square uprights and cross members extruded from 6061-T6 aluminum
Tray runners extruded from 1-7/16 x 1-7/8 in. 6061-T6 aluminum
The Alexander Industries T-422 Bun pan rack
The Alexander Industries T-422 is a work table height end loading aluminum bun pan rack that holds 12 full-size 18 x 26 in. bun pans on 2 in. centers. At 35 in. tall it slides under a work table or parks at the end of the line as a low staging shelf for pizzerias, bakeries and commissaries that want a dozen pans close at hand. The 2 in. slide spacing packs more flat product such as cookies, pizza dough balls and portioned proteins into the same short frame. The rack rolls on four swivel casters and arrives knocked down for assembly, with factory assembly available as an option.
2 In. Slide Spacing for 12 Pans
Twelve pans on 2 in. centers doubles the count of the 4 in. version for flat product that does not need headroom. Pans load from the 20 in. end, so the rack can sit with one side against a wall or table leg and still be worked from the front. The flat top frame doubles as a landing spot at counter height.
6061-T6 Aluminum Extrusion Frame
Uprights and cross members are 1 in. square 6061-T6 aluminum extrusion, and each tray runner is a 1-7/16 x 1-7/8 in. extrusion of the same alloy. Aluminum will not rust in a walk-in cooler or under a daily hose-down. The connecting brackets for the bun pan shelves are included and stamped from .100 in. thick 3003-H14 aluminum, and the frame is assembled with aircraft quality aluminum rivets so it stays square in daily use.
5 In. Ball Bearing Swivel Casters
Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires let you roll a loaded rack across tile or sealed concrete without scuffing the floor. Two locking casters can be added when the rack parks under a table, along with donut bumpers, a tray stopper, a sanitary rack cover or a plastic cutting board for the top.
Features & Benefits
-
Holds 12 full-size 18 x 26 in. bun pans on 2 in. slide spacing for staging, proofing and cooling
-
Work table height 35 in. frame that rolls under a prep table or stands beside it as a staging shelf
-
End loading open frame so pans slide in from the 20 in. end without lifting over a side rail
-
1 in. square uprights and cross members extruded from 6061-T6 aluminum
-
Tray runners extruded from 1-7/16 x 1-7/8 in. 6061-T6 aluminum
-
Connecting brackets for the bun pan shelves included, stamped from .100 in. thick 3003-H14 high tensile aluminum
-
Assembled with high tensile aircraft quality aluminum rivets
-
Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires
-
Arrives knocked down for on-site assembly, factory assembly available as an option
-
Optional accessories: donut bumpers, tray stopper, sanitary rack cover, two locking casters, plastic cutting board
Resources & Downloads
Specifications
| Pan Size Accommodated | 18 x 26 in. bun pans |
| Pan Capacity | 12 pans |
| Slide Spacing | 2 in. |
| Loading Style | End loading |
| Height Class | Work table height |
| Overall Width | 20 in. |
| Overall Depth | 26 in. |
| Overall Height | 35 in. |
| Upright and Cross Member | 1 in. square 6061-T6 aluminum extrusion |
| Tray Runner | 1-7/16 x 1-7/8 in. 6061-T6 aluminum extrusion |
| Connecting Brackets | .100 in. 3003-H14 aluminum stamping, included |
| Fasteners | Aircraft quality aluminum rivets |
| Casters | 5 in. swivel, ball bearing |
| Caster Tires | Non-marking hard rubber |
| Mobility | Mobile |
| Assembly | Knocked down, factory assembly optional |
| Shipping Weight | 34 lb |
Manufacturer's Warranty
-
5 Year
Casters
-
Lifetime Year
Parts
Certifications & Approvals
-
NSF Approved
