The Alexander Industries T-423 Bun pan rack
The Alexander Industries T-423 is a work table height end loading aluminum bun pan rack that holds 16 full-size 18 x 26 in. bun pans on 1-1/2 in. centers. It stands 35 in. tall and rolls under a prep table or beside a walk-in door as a low, dense staging shelf for bakeries, pizzerias and commissaries that move a lot of flat product. The 1-1/2 in. slide spacing is the tightest pitch in the T series and fits the most pans of sheeted dough, cookies or portioned items in a short footprint. The rack rolls on four swivel casters and arrives knocked down for assembly, with factory assembly available as an option.
1-1/2 In. Slide Spacing for 16 Pans
Sixteen pans on 1-1/2 in. centers is the highest capacity in the T series for flat, uncovered product. Pans load from the 20 in. end, so the rack can sit with one side against a wall or table leg and still be worked from the front. The flat top frame doubles as a landing spot at counter height.
6061-T6 Aluminum Extrusion Frame
Uprights and cross members are 1 in. square 6061-T6 aluminum extrusion, and each tray runner is a 1-7/16 x 1-7/8 in. extrusion of the same alloy. Aluminum will not rust in a walk-in cooler or under a daily hose-down. The connecting brackets for the bun pan shelves are included and stamped from .100 in. thick 3003-H14 aluminum, and the frame is assembled with aircraft quality aluminum rivets so it stays square in daily use.
5 In. Ball Bearing Swivel Casters
Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires let you roll a loaded rack across tile or sealed concrete without scuffing the floor. Two locking casters can be added when the rack parks under a table, along with donut bumpers, a tray stopper, a sanitary rack cover or a plastic cutting board for the top.
Features & Benefits
-
Holds 16 full-size 18 x 26 in. bun pans on 1-1/2 in. slide spacing for staging, proofing and cooling
-
Work table height 35 in. frame that rolls under a prep table or stands beside it as a staging shelf
-
End loading open frame so pans slide in from the 20 in. end without lifting over a side rail
-
1 in. square uprights and cross members extruded from 6061-T6 aluminum
-
Tray runners extruded from 1-7/16 x 1-7/8 in. 6061-T6 aluminum
-
Connecting brackets for the bun pan shelves included, stamped from .100 in. thick 3003-H14 high tensile aluminum
-
Assembled with high tensile aircraft quality aluminum rivets
-
Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires
-
Arrives knocked down for on-site assembly, factory assembly available as an option
-
Optional accessories: donut bumpers, tray stopper, sanitary rack cover, two locking casters, plastic cutting board
Free Shipping 48 Contiguous states & DC only.
In Stock: Ships in 1-2 Business Days
Holds 16 full-size 18 x 26 in. bun pans on 1-1/2 in. slide spacing for staging, proofing and cooling
Work table height 35 in. frame that rolls under a prep table or stands beside it as a staging shelf
End loading open frame so pans slide in from the 20 in. end without lifting over a side rail
1 in. square uprights and cross members extruded from 6061-T6 aluminum
Tray runners extruded from 1-7/16 x 1-7/8 in. 6061-T6 aluminum
The Alexander Industries T-423 Bun pan rack
The Alexander Industries T-423 is a work table height end loading aluminum bun pan rack that holds 16 full-size 18 x 26 in. bun pans on 1-1/2 in. centers. It stands 35 in. tall and rolls under a prep table or beside a walk-in door as a low, dense staging shelf for bakeries, pizzerias and commissaries that move a lot of flat product. The 1-1/2 in. slide spacing is the tightest pitch in the T series and fits the most pans of sheeted dough, cookies or portioned items in a short footprint. The rack rolls on four swivel casters and arrives knocked down for assembly, with factory assembly available as an option.
1-1/2 In. Slide Spacing for 16 Pans
Sixteen pans on 1-1/2 in. centers is the highest capacity in the T series for flat, uncovered product. Pans load from the 20 in. end, so the rack can sit with one side against a wall or table leg and still be worked from the front. The flat top frame doubles as a landing spot at counter height.
6061-T6 Aluminum Extrusion Frame
Uprights and cross members are 1 in. square 6061-T6 aluminum extrusion, and each tray runner is a 1-7/16 x 1-7/8 in. extrusion of the same alloy. Aluminum will not rust in a walk-in cooler or under a daily hose-down. The connecting brackets for the bun pan shelves are included and stamped from .100 in. thick 3003-H14 aluminum, and the frame is assembled with aircraft quality aluminum rivets so it stays square in daily use.
5 In. Ball Bearing Swivel Casters
Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires let you roll a loaded rack across tile or sealed concrete without scuffing the floor. Two locking casters can be added when the rack parks under a table, along with donut bumpers, a tray stopper, a sanitary rack cover or a plastic cutting board for the top.
Features & Benefits
-
Holds 16 full-size 18 x 26 in. bun pans on 1-1/2 in. slide spacing for staging, proofing and cooling
-
Work table height 35 in. frame that rolls under a prep table or stands beside it as a staging shelf
-
End loading open frame so pans slide in from the 20 in. end without lifting over a side rail
-
1 in. square uprights and cross members extruded from 6061-T6 aluminum
-
Tray runners extruded from 1-7/16 x 1-7/8 in. 6061-T6 aluminum
-
Connecting brackets for the bun pan shelves included, stamped from .100 in. thick 3003-H14 high tensile aluminum
-
Assembled with high tensile aircraft quality aluminum rivets
-
Four 5 in. swivel casters with ball bearings and non-marking hard rubber tires
-
Arrives knocked down for on-site assembly, factory assembly available as an option
-
Optional accessories: donut bumpers, tray stopper, sanitary rack cover, two locking casters, plastic cutting board
Resources & Downloads
Specifications
| Pan Size Accommodated | 18 x 26 in. bun pans |
| Pan Capacity | 16 pans |
| Slide Spacing | 1-1/2 in. |
| Loading Style | End loading |
| Height Class | Work table height |
| Overall Width | 20 in. |
| Overall Depth | 26 in. |
| Overall Height | 35 in. |
| Upright and Cross Member | 1 in. square 6061-T6 aluminum extrusion |
| Tray Runner | 1-7/16 x 1-7/8 in. 6061-T6 aluminum extrusion |
| Connecting Brackets | .100 in. 3003-H14 aluminum stamping, included |
| Fasteners | Aircraft quality aluminum rivets |
| Casters | 5 in. swivel, ball bearing |
| Caster Tires | Non-marking hard rubber |
| Mobility | Mobile |
| Assembly | Knocked down, factory assembly optional |
| Shipping Weight | 36 lb |
Manufacturer's Warranty
-
5 Year
Casters
-
Lifetime Year
Parts
Certifications & Approvals
-
NSF Approved
