The Everest Refrigeration ESR2D4 Reach-In Refrigerator
The Everest ESR2D4 is the drawer-heavy flagship of Everest's ES Series door and drawer combo family, built for kitchens running two drawer stations side by side so each cook on a 49 5/8 inch stretch of line pulls product at hand height all shift. Two solid half doors up top cover four adjustable wire shelves for backup stock, while four stainless steel drawers below, two under each door, slide product straight out to the cooks instead of making them crouch and dig behind swing doors. All six openings share one open 48 cubic foot interior, and at under 32 inches deep the cabinet holds the same wall line as your worktables.
Slide-Out Blizzard R290 Cartridge that Swaps without On-Site Brazing
The condensing unit is a top mounted, self-contained Blizzard R290 cartridge that is fully detachable and replaceable in the field with no on-site brazing. Unlike a conventional sealed system repair that can park a cabinet out of service while a refrigeration tech opens the circuit, a cartridge swap gets the box back to work the same visit. The cartridge runs natural R290 refrigerant with zero ozone depletion potential and a global warming potential of three.
Electronically commutated fan motors pull the cabinet to temperature quickly while drawing less power, and the auto defrost cycle starts on a timer and ends on temperature, so it runs only as long as the coil needs. The condensate pan maintains itself with no external drain line or electric heater, which is one less floor penetration in your install. An auto-reverse condenser fan supports compressor ventilation and helps keep the condenser coil clean between cleanings, and pressure relief devices let staff re-open a just-closed door instead of waiting out the vacuum.
Two Solid Half Doors over Four Ball-Bearing Drawers with Pre-Installed Door Locks
Both half doors are heavy duty stainless steel inside and out with the same 2.5 inch high density polyurethane insulation as the cabinet walls, so the swing side of the box insulates as well as the rest of it. Each self-closes through an adjustable torsion system for a positive seal, carries a high strength recessed handle that will not catch passing carts, and comes with a pre-installed lock; the locks cover the doors only, not the drawers. All four drawers ride in thick gauge stainless steel frames on low-friction ball bearings, so a loaded drawer rolls out with one hand instead of fighting the cook mid-rush. Snap-in magnetic gaskets on the doors and drawers pop out for cleaning or replacement without tools, and frame heaters prevent exterior moisture build up on humid days.
48 Cu. Ft. Open Interior Built in Heavy Duty Stainless Steel
Inside there are no dividing walls, just one open compartment serving the doors and drawers, with four epoxy coated steel wire shelves on height adjustable stainless steel clips behind the half doors. The interior and exterior are heavy duty stainless steel with rounded corners that will not snag knuckles or towels, the top, bottom and rear are galvanized steel, and 2.5 inch high density polyurethane insulation fills the cabinet walls. A full-length air duct and airflow guard keep cold air moving through the whole cavity, and silicone coated, shatter-proof LED lighting gives bright, high color illumination with low heat output. The cabinet rolls on four 5 inch swivel casters with locks on the front set.
Digital Controller that Holds 33°F to 54°F with an Overheat Alarm
A multi-function digital controller with an easy to read LED display ships factory preset at 35°F and adjusts anywhere from 33°F to 54°F. An audible overheat alarm watches the compressor and condenser coil and sounds before a developing problem turns into lost product. Everest backs the unit with 3 year parts and labor, 5 year electrical, and 10 year compressor coverage, supported through its service agent network.
If the stock configuration does not match your line, Everest offers additional shelving, 3 inch locking swivel casters in place of the standard 5 inch set, and height adjustable interchangeable legs from 3.5 to 6 inches.
Keep in mind this is a refrigerator only, holding 33°F to 54°F; the ES Series includes freezer and dual temperature versions if you need frozen storage. Four drawers earn their keep where two stations pull product at the line all day, while a kitchen that mostly restocks in bulk is better matched to the one full door version with two drawers, and a shelving-only operation to the all-door two section cabinet in the same series. Power is a standard 115V connection on a 9 foot cord, with no dedicated high-voltage circuit needed.
Features & Benefits
-
Double drawer-station box for lines where two cooks pull product at hand height all shift
-
Stores 48 cu. ft. behind two solid half doors and four pull-out drawers
-
Swaps the entire Blizzard R290 cooling cartridge in the field without on-site brazing
-
Holds product anywhere from 33°F to 54°F on a digital controller preset at 35°F
-
Slides loaded drawers on thick gauge stainless steel frames with low-friction ball bearings
-
Cuts energy draw with ECM fan motors and low-heat, shatter-proof LED lighting
-
Defrosts on a time-initiated, temperature-terminated cycle with no operator input
-
Drains condensate into a self-maintaining pan with no external drain or electric heater
-
Seals both half doors with self-closing adjustable torsion hinges for a positive seal
-
Cleans door and drawer gaskets fast with tool-free, snap-in magnetic design
-
Locks both half doors overnight with pre-installed locks to keep shelved stock secure
-
Adjusts four epoxy coated wire shelves on stainless steel height-adjustable clips
-
Prevents exterior moisture build up with standard door frame heaters
-
Rolls on four 5 in. swivel casters with locks on the front set
-
Plugs in pre-wired and ready to run on a 9 ft cord, no electrician needed
Free Shipping 48 Contiguous states & DC only.
In Stock: Ships in 1-2 Business Days
Double drawer-station box for lines where two cooks pull product at hand height all shift
Stores 48 cu. ft. behind two solid half doors and four pull-out drawers
Swaps the entire Blizzard R290 cooling cartridge in the field without on-site brazing
Holds product anywhere from 33°F to 54°F on a digital controller preset at 35°F
Slides loaded drawers on thick gauge stainless steel frames with low-friction ball bearings
The Everest Refrigeration ESR2D4 Reach-In Refrigerator
The Everest ESR2D4 is the drawer-heavy flagship of Everest's ES Series door and drawer combo family, built for kitchens running two drawer stations side by side so each cook on a 49 5/8 inch stretch of line pulls product at hand height all shift. Two solid half doors up top cover four adjustable wire shelves for backup stock, while four stainless steel drawers below, two under each door, slide product straight out to the cooks instead of making them crouch and dig behind swing doors. All six openings share one open 48 cubic foot interior, and at under 32 inches deep the cabinet holds the same wall line as your worktables.
Slide-Out Blizzard R290 Cartridge that Swaps without On-Site Brazing
The condensing unit is a top mounted, self-contained Blizzard R290 cartridge that is fully detachable and replaceable in the field with no on-site brazing. Unlike a conventional sealed system repair that can park a cabinet out of service while a refrigeration tech opens the circuit, a cartridge swap gets the box back to work the same visit. The cartridge runs natural R290 refrigerant with zero ozone depletion potential and a global warming potential of three.
Electronically commutated fan motors pull the cabinet to temperature quickly while drawing less power, and the auto defrost cycle starts on a timer and ends on temperature, so it runs only as long as the coil needs. The condensate pan maintains itself with no external drain line or electric heater, which is one less floor penetration in your install. An auto-reverse condenser fan supports compressor ventilation and helps keep the condenser coil clean between cleanings, and pressure relief devices let staff re-open a just-closed door instead of waiting out the vacuum.
Two Solid Half Doors over Four Ball-Bearing Drawers with Pre-Installed Door Locks
Both half doors are heavy duty stainless steel inside and out with the same 2.5 inch high density polyurethane insulation as the cabinet walls, so the swing side of the box insulates as well as the rest of it. Each self-closes through an adjustable torsion system for a positive seal, carries a high strength recessed handle that will not catch passing carts, and comes with a pre-installed lock; the locks cover the doors only, not the drawers. All four drawers ride in thick gauge stainless steel frames on low-friction ball bearings, so a loaded drawer rolls out with one hand instead of fighting the cook mid-rush. Snap-in magnetic gaskets on the doors and drawers pop out for cleaning or replacement without tools, and frame heaters prevent exterior moisture build up on humid days.
48 Cu. Ft. Open Interior Built in Heavy Duty Stainless Steel
Inside there are no dividing walls, just one open compartment serving the doors and drawers, with four epoxy coated steel wire shelves on height adjustable stainless steel clips behind the half doors. The interior and exterior are heavy duty stainless steel with rounded corners that will not snag knuckles or towels, the top, bottom and rear are galvanized steel, and 2.5 inch high density polyurethane insulation fills the cabinet walls. A full-length air duct and airflow guard keep cold air moving through the whole cavity, and silicone coated, shatter-proof LED lighting gives bright, high color illumination with low heat output. The cabinet rolls on four 5 inch swivel casters with locks on the front set.
Digital Controller that Holds 33°F to 54°F with an Overheat Alarm
A multi-function digital controller with an easy to read LED display ships factory preset at 35°F and adjusts anywhere from 33°F to 54°F. An audible overheat alarm watches the compressor and condenser coil and sounds before a developing problem turns into lost product. Everest backs the unit with 3 year parts and labor, 5 year electrical, and 10 year compressor coverage, supported through its service agent network.
If the stock configuration does not match your line, Everest offers additional shelving, 3 inch locking swivel casters in place of the standard 5 inch set, and height adjustable interchangeable legs from 3.5 to 6 inches.
Keep in mind this is a refrigerator only, holding 33°F to 54°F; the ES Series includes freezer and dual temperature versions if you need frozen storage. Four drawers earn their keep where two stations pull product at the line all day, while a kitchen that mostly restocks in bulk is better matched to the one full door version with two drawers, and a shelving-only operation to the all-door two section cabinet in the same series. Power is a standard 115V connection on a 9 foot cord, with no dedicated high-voltage circuit needed.
Features & Benefits
-
Double drawer-station box for lines where two cooks pull product at hand height all shift
-
Stores 48 cu. ft. behind two solid half doors and four pull-out drawers
-
Swaps the entire Blizzard R290 cooling cartridge in the field without on-site brazing
-
Holds product anywhere from 33°F to 54°F on a digital controller preset at 35°F
-
Slides loaded drawers on thick gauge stainless steel frames with low-friction ball bearings
-
Cuts energy draw with ECM fan motors and low-heat, shatter-proof LED lighting
-
Defrosts on a time-initiated, temperature-terminated cycle with no operator input
-
Drains condensate into a self-maintaining pan with no external drain or electric heater
-
Seals both half doors with self-closing adjustable torsion hinges for a positive seal
-
Cleans door and drawer gaskets fast with tool-free, snap-in magnetic design
-
Locks both half doors overnight with pre-installed locks to keep shelved stock secure
-
Adjusts four epoxy coated wire shelves on stainless steel height-adjustable clips
-
Prevents exterior moisture build up with standard door frame heaters
-
Rolls on four 5 in. swivel casters with locks on the front set
-
Plugs in pre-wired and ready to run on a 9 ft cord, no electrician needed
Resources & Downloads
Specifications
| Temp Type | Refrigerator |
| Temperature Range | 33°F to 54°F |
| Factory Preset Temperature | 35°F |
| Net Capacity (Cu. Ft.) | 48 |
| Door Count | 2 Half Doors, 4 Drawers |
| Door Style | Swing Solid + Drawer |
| Door Material | Stainless Steel Interior/Exterior |
| Door Width | 24" Each |
| Door Features | Self-Closing, Recessed Handles, Pre-Installed Locks (Doors Only) |
| Drawer Frames | Thick Gauge Stainless Steel, Low-Friction Ball Bearings |
| Door and Drawer Gaskets | Snap-In Magnetic |
| Frame Heaters | Standard |
| Shelves | 4 Epoxy Coated Steel Wire |
| Shelf Clips | Height Adjustable Stainless Steel |
| Interior / Exterior Finish | Heavy Duty Stainless Steel, Rounded Corners |
| Top, Bottom and Rear | Galvanized Steel |
| Insulation | 2.5" High Density Polyurethane (Cabinet and Doors) |
| Lighting | Silicone Coated, Shatter-Proof LED |
| Refrigerant | R-290 |
| Compressor HP | 1/3 |
| Compressor Location | Top Mount |
| BTU/Hr | 2,311 |
| Fan Motors | Electronically Commutated (ECM) |
| Condenser and Evaporator Coils | Large Capacity, Corrosion-Resistant |
| Condenser Fan | High Performance, Auto-Reverse |
| Defrost | Auto, Time-Initiated and Temperature-Terminated |
| Condensate Management | Self-Maintaining Drain Pan, No External Drain or Heater |
| Pressure Relief Devices | Standard, For Rapid Cabinet Re-Entry |
| Overheat Alarm | Audible, Compressor and Condenser Coil |
| Power (V-Hz-Ph) | 115-60-1 |
| Full Load Amps | 3.0 |
| NEMA Plug Type | NEMA 5-15P |
| Cord Length | 9 Ft. |
| Feed Wires | 3 With Ground |
| Casters | Four 5" Swivel, Locks on Front Set |
| Exterior Length | 49 5/8" |
| Exterior Depth | 31 5/8" |
| Depth With Doors Open | 54 1/2" |
| Exterior Height | 74 1/4" |
| Overall Height (With 5" Casters) | 79 1/4" |
| Crated Weight | 479 Lbs. |
| Optional Accessories | Additional Shelving, 3" Caster Assembly (CASA3-01), 3.5"-6" Interchangeable Legs (AJL03-00) |
Manufacturer's Warranty
-
10 Year
Compressor
-
3 Year
Labor
-
3 Year
Parts
-
5 Year
Electrical
Certifications & Approvals
-
NSF Approved
-
ETL US & Canada
-
ETL Sanitation
