The Howard McCray SC-OP35E-8S-W-LED Open Merchandiser
The SC-OP35E-8S-W-LED is a 99 in. self-contained open produce merchandiser from Howard McCray's 35E Series, built for grab-and-go produce, dairy, and packaged-food displays in supermarkets, convenience stores, and foodservice. Its endless design lets you line up multiple cases into a continuous run, and three lit shelf rows put cold product at eye level for impulse sales.
Display And Merchandising
Three rows of lit shelves stage produce and packaged product up the full height of the case, and a 15 in. product-reflecting mirror across the top makes the display look deeper and fuller than it is. Sloped end panels and an endless cabinet design let you butt cases together into a continuous merchandising run, and bright LED lighting shows off color and freshness without adding heat to the load.
Refrigeration And Power
A self-contained 1-1/4 HP refrigeration system holds the open display cold without a remote rack, so the case plugs in and runs on its own. It is rated to operate at 75°F and 55 percent relative humidity, runs on 115/208-230-volt single-phase power at 16 amps through a NEMA L14-20P cord and plug, and only pre-cooled product should be loaded so the system holds temperature through service.
Build And Finish
The case carries a white exterior and interior for a clean, consistent merchandising look, with a choice of three sloped end-panel designs. The cabinet is equipped with drains for meltwater and condensate, and the open-front format keeps product visible and within easy reach for shoppers.
Installation And Fit
The SC-OP35E-8S-W-LED measures 99 in. long by 34.5 in. deep by 78.5 in. high and ships at about 1,350 lb. A drain connection is required, so check local building codes, and a qualified refrigeration mechanic should set up and dial in the controls, since correct settings are critical to performance and are the customer's responsibility.
Features & Benefits
-
Self-contained open produce merchandiser for grab-and-go supermarket and c-store displays
-
Endless design butts cases together into a continuous merchandising run
-
Three rows of lit shelves stage product up the full height for impulse sales
-
15 in. product-reflecting mirror makes the display look deeper and fuller
-
Bright LED lighting shows off color and freshness without adding heat
-
Choice of three sloped end-panel designs for a finished run
-
White exterior and interior for a clean, consistent merchandising look
-
Self-contained refrigeration plugs in and runs without a remote rack
-
Open front keeps product visible and within easy reach for shoppers
-
Cabinet equipped with drains for meltwater and condensate
Free Shipping 48 Contiguous states & DC only.
In Stock: Ships in 1-2 Business Days
Self-contained open produce merchandiser for grab-and-go supermarket and c-store displays
Endless design butts cases together into a continuous merchandising run
Three rows of lit shelves stage product up the full height for impulse sales
15 in. product-reflecting mirror makes the display look deeper and fuller
Bright LED lighting shows off color and freshness without adding heat
The Howard McCray SC-OP35E-8S-W-LED Open Merchandiser
The SC-OP35E-8S-W-LED is a 99 in. self-contained open produce merchandiser from Howard McCray's 35E Series, built for grab-and-go produce, dairy, and packaged-food displays in supermarkets, convenience stores, and foodservice. Its endless design lets you line up multiple cases into a continuous run, and three lit shelf rows put cold product at eye level for impulse sales.
Display And Merchandising
Three rows of lit shelves stage produce and packaged product up the full height of the case, and a 15 in. product-reflecting mirror across the top makes the display look deeper and fuller than it is. Sloped end panels and an endless cabinet design let you butt cases together into a continuous merchandising run, and bright LED lighting shows off color and freshness without adding heat to the load.
Refrigeration And Power
A self-contained 1-1/4 HP refrigeration system holds the open display cold without a remote rack, so the case plugs in and runs on its own. It is rated to operate at 75°F and 55 percent relative humidity, runs on 115/208-230-volt single-phase power at 16 amps through a NEMA L14-20P cord and plug, and only pre-cooled product should be loaded so the system holds temperature through service.
Build And Finish
The case carries a white exterior and interior for a clean, consistent merchandising look, with a choice of three sloped end-panel designs. The cabinet is equipped with drains for meltwater and condensate, and the open-front format keeps product visible and within easy reach for shoppers.
Installation And Fit
The SC-OP35E-8S-W-LED measures 99 in. long by 34.5 in. deep by 78.5 in. high and ships at about 1,350 lb. A drain connection is required, so check local building codes, and a qualified refrigeration mechanic should set up and dial in the controls, since correct settings are critical to performance and are the customer's responsibility.
Features & Benefits
-
Self-contained open produce merchandiser for grab-and-go supermarket and c-store displays
-
Endless design butts cases together into a continuous merchandising run
-
Three rows of lit shelves stage product up the full height for impulse sales
-
15 in. product-reflecting mirror makes the display look deeper and fuller
-
Bright LED lighting shows off color and freshness without adding heat
-
Choice of three sloped end-panel designs for a finished run
-
White exterior and interior for a clean, consistent merchandising look
-
Self-contained refrigeration plugs in and runs without a remote rack
-
Open front keeps product visible and within easy reach for shoppers
-
Cabinet equipped with drains for meltwater and condensate
Resources & Downloads
Specifications
| Type | Self-Contained Open Merchandiser |
| Length | 99 in. |
| Depth | 34.5 in. |
| Height | 78.5 in. |
| Refrigeration | Self-Contained |
| Horsepower | 1-1/4 HP |
| Shelves | 3 Rows, Lit |
| Mirror | 15 in. Product-Reflecting |
| End Panels | Sloped, 3 Designs |
| Lighting | LED |
| Voltage | 115/208-230 |
| Amps | 16.0 |
| Plug | NEMA L14-20P |
| Drain | Required |
| Operating Conditions | 75°F, 55% RH |
| Exterior / Interior | White |
| Ship Weight | 1,350 lbs |
Manufacturer's Warranty
-
1 Year
Labor
-
1 Year
Parts
-
5 Year
Compressor
