The Hydra-Kool KGV-MR-3-R Open Air Merchandiser
The Hydra-Kool KGV-MR-3-R is a three-door remote grab-and-go case that stretches to just over 75 inches wide, giving you 56.37 cubic feet of refrigerated display volume. That extra section compared to the two-door model means roughly 50 percent more shelf space without any change in depth or height, making it a natural fit for grocery aisles, deli areas, or large convenience stores where you want a longer merchandising run. Three hinged glass doors on the front let customers serve themselves, and three solid doors on the rear give your team a dedicated restocking lane.
Front and Rear Loading with Forced Air Cooling and Night Curtain
The front of the case uses hinged tempered glass doors that let customers browse and grab items directly, while solid rear loading doors give your staff a separate restocking path that does not interrupt the shopping side. Each section holds five adjustable shelves that can be tilted and fitted with product stops, so bottles, cans, and packaged items stay put even on an angle. A retractable night curtain pulls down across the front opening after hours, helping the case hold temperature overnight and reducing compressor run time when the store is closed.
Forced air refrigeration keeps the interior between 33 and 40 degrees Fahrenheit, and a digital controller manages both temperature and defrost cycles. The case uses R404a refrigerant and is rated for environments up to 75 degrees Fahrenheit and 55 percent relative humidity. A floor drain connection is required for condensate removal, and the case must be hard-wired with no plug.
LED Lighting and Multiplexable Construction
LED strips in the canopy and under each shelf illuminate products from above and below, keeping labels readable and colors accurate without adding meaningful heat to the cabinet. Unlike fluorescent tubes that need regular replacement, LEDs maintain consistent brightness across thousands of hours and draw less power, which helps offset overall energy consumption on a case this size.
The exterior features a silver PVC-coated steel front panel with foamed polystyrene black end panels and a black steel kick plate. When you need a longer merchandising run, multiple cases can be joined side by side using optional joining kits, and the end panels on interior units can be removed for a seamless look. The interior is PVC-coated steel in gray for easy wipe-down cleaning, and CFC-free injected foam insulation lines the cabinet walls. Standard leveling feet keep the unit stable on uneven floors.
The KGV-MR-3-R measures 75.4 inches wide by 31-1/2 inches deep by 77-3/4 inches high. As a remote unit, the case draws 3.45 total amps and produces 4,430 BTUs. Net weight is 899 lbs and shipping weight is 1,166 lbs. The unit ships in a crate measuring 78 by 39 by 85 inches.
About Hydra-Kool
Hydra-Kool manufactures refrigerated display cases designed for food retail and foodservice environments where product visibility and temperature control are critical. The line includes bakery, deli, seafood, and gelato cases, along with open display merchandisers and glass door wall units. Equipment is configured to support merchandising while maintaining consistent holding conditions across different product types. Cases are built with accessible components to allow for routine cleaning and service. Hydra-Kool units are used in supermarkets, specialty shops, and prepared food operations. Replacement parts support and established service channels help operators maintain performance and manage ongoing upkeep.
Features & Benefits
-
Three-door high volume grab-and-go case with front and rear loading for separate customer and staff access
-
56.37 cu. ft. display volume across (5) adjustable shelves per section
-
Hinged tempered glass front doors for customer self-service
-
Solid rear loading doors for back-of-house restocking
-
Holds 33°F to 40°F, forced air refrigeration
-
Designed for remote condensing unit (not included)
-
R404a refrigerant
-
Retractable night curtain for after-hours energy savings
-
LED lighting in canopy and under each shelf
-
Height-adjustable shelves can be tilted with product stops
-
Temperature and defrost regulated by digital controller
-
CFC-free injected foam insulation
-
PVC-coated steel gray interior
-
Silver colored PVC-coated steel front panel
-
Foamed polystyrene black end panels
-
Black steel kick plate
-
Multiplexable with optional joining kits
-
Standard leveling feet
-
Hard-wired, floor drain required
-
3.45 total amps, 4,430 BTUs
-
Engineered for locations not exceeding 75°F and 55% RH
Free Shipping 48 Contiguous states & DC only.
In Stock: Ships in 1-2 Business Days
Three-door high volume grab-and-go case with front and rear loading for separate customer and staff access
56.37 cu. ft. display volume across (5) adjustable shelves per section
Hinged tempered glass front doors for customer self-service
Solid rear loading doors for back-of-house restocking
Holds 33°F to 40°F, forced air refrigeration
The Hydra-Kool KGV-MR-3-R Open Air Merchandiser
The Hydra-Kool KGV-MR-3-R is a three-door remote grab-and-go case that stretches to just over 75 inches wide, giving you 56.37 cubic feet of refrigerated display volume. That extra section compared to the two-door model means roughly 50 percent more shelf space without any change in depth or height, making it a natural fit for grocery aisles, deli areas, or large convenience stores where you want a longer merchandising run. Three hinged glass doors on the front let customers serve themselves, and three solid doors on the rear give your team a dedicated restocking lane.
Front and Rear Loading with Forced Air Cooling and Night Curtain
The front of the case uses hinged tempered glass doors that let customers browse and grab items directly, while solid rear loading doors give your staff a separate restocking path that does not interrupt the shopping side. Each section holds five adjustable shelves that can be tilted and fitted with product stops, so bottles, cans, and packaged items stay put even on an angle. A retractable night curtain pulls down across the front opening after hours, helping the case hold temperature overnight and reducing compressor run time when the store is closed.
Forced air refrigeration keeps the interior between 33 and 40 degrees Fahrenheit, and a digital controller manages both temperature and defrost cycles. The case uses R404a refrigerant and is rated for environments up to 75 degrees Fahrenheit and 55 percent relative humidity. A floor drain connection is required for condensate removal, and the case must be hard-wired with no plug.
LED Lighting and Multiplexable Construction
LED strips in the canopy and under each shelf illuminate products from above and below, keeping labels readable and colors accurate without adding meaningful heat to the cabinet. Unlike fluorescent tubes that need regular replacement, LEDs maintain consistent brightness across thousands of hours and draw less power, which helps offset overall energy consumption on a case this size.
The exterior features a silver PVC-coated steel front panel with foamed polystyrene black end panels and a black steel kick plate. When you need a longer merchandising run, multiple cases can be joined side by side using optional joining kits, and the end panels on interior units can be removed for a seamless look. The interior is PVC-coated steel in gray for easy wipe-down cleaning, and CFC-free injected foam insulation lines the cabinet walls. Standard leveling feet keep the unit stable on uneven floors.
The KGV-MR-3-R measures 75.4 inches wide by 31-1/2 inches deep by 77-3/4 inches high. As a remote unit, the case draws 3.45 total amps and produces 4,430 BTUs. Net weight is 899 lbs and shipping weight is 1,166 lbs. The unit ships in a crate measuring 78 by 39 by 85 inches.
About Hydra-Kool
Hydra-Kool manufactures refrigerated display cases designed for food retail and foodservice environments where product visibility and temperature control are critical. The line includes bakery, deli, seafood, and gelato cases, along with open display merchandisers and glass door wall units. Equipment is configured to support merchandising while maintaining consistent holding conditions across different product types. Cases are built with accessible components to allow for routine cleaning and service. Hydra-Kool units are used in supermarkets, specialty shops, and prepared food operations. Replacement parts support and established service channels help operators maintain performance and manage ongoing upkeep.
Features & Benefits
-
Three-door high volume grab-and-go case with front and rear loading for separate customer and staff access
-
56.37 cu. ft. display volume across (5) adjustable shelves per section
-
Hinged tempered glass front doors for customer self-service
-
Solid rear loading doors for back-of-house restocking
-
Holds 33°F to 40°F, forced air refrigeration
-
Designed for remote condensing unit (not included)
-
R404a refrigerant
-
Retractable night curtain for after-hours energy savings
-
LED lighting in canopy and under each shelf
-
Height-adjustable shelves can be tilted with product stops
-
Temperature and defrost regulated by digital controller
-
CFC-free injected foam insulation
-
PVC-coated steel gray interior
-
Silver colored PVC-coated steel front panel
-
Foamed polystyrene black end panels
-
Black steel kick plate
-
Multiplexable with optional joining kits
-
Standard leveling feet
-
Hard-wired, floor drain required
-
3.45 total amps, 4,430 BTUs
-
Engineered for locations not exceeding 75°F and 55% RH
Resources & Downloads
See all from Hydra-Kool
Specifications
| Overall Dimensions (W x D x H) | 75.4" x 31-1/2" x 77-3/4" |
| Number of Doors | 3 x 23-1/2" (Front Hinged Glass + Rear Solid) |
| Display Volume | 56.37 cu. ft. |
| Shelves Per Section | (5) Adjustable, Tiltable with Product Stops |
| Temperature Range | 33°F to 40°F |
| Refrigeration Type | Forced Air, Remote |
| Refrigerant | R404a |
| Total Amps | 3.45 A |
| BTU Rating | 4,430 |
| Night Curtain | Retractable |
| Lighting | LED in Canopy and Under Each Shelf |
| Temperature Control | Digital Controller (Temperature and Defrost) |
| Insulation | CFC-Free Injected Foam |
| Interior Finish | PVC-Coated Steel, Gray |
| Front Panel | Silver Colored PVC-Coated Steel |
| End Panels | Foamed Polystyrene, Black |
| Kick Plate | Black Steel |
| Electrical Connection | Hard-Wired (No Plug) |
| Floor Drain | Required |
| Multiplexable | Yes (Joining Kit Optional) |
| Standard Mounting | Leveling Feet |
| Operating Environment | Max 75°F, 55% RH |
| Net Weight | 899 lbs |
| Shipping Weight | 1,166 lbs |
| Crate Size (L x W x H) | 78" x 39" x 85" |
Manufacturer's Warranty
-
1 Year
Labor
-
1 Year
Parts
Certifications & Approvals
-
ETL US & Canada
-
ETL Sanitation
